The Miruc Monocular Measure Scope Unit is devised as a reliable and highly versatile scope for ideal mounting onto machinery and devices. Miruc's microscope unit is equipped with a slider as standard. It can be used attached to a φ14 shaft. As the Miruc's microscope unit is compact and lightweight, it can be combined in various ways with special stands. Similar with Hubble Space Telescope, Miruc's microscope line-up are primarily built with the finest technology in optical lenses to magnify the object.

Furthermore, Miruc's microscope unit can be combined with Miruc's digital catch, Miruc's digital camera adapter and other Miruc's accesories for convenient application in quality inspection of electronic boards, metallography research, Biology-Medical research and even manufacturing or maintenance of plastic mold on a live peer review through WIFI and internet connection.

The Miruc's microscope line-up includes:

  1. Miruc's basic type MS series is a long-selling product with a wide range of demand, from standalone use to integration into machinery and devices. (OCD10x, OBD2x included)
  2. The MFS series can be used in combination with an ordinary eyepiece lens or a traveling micrometer. Any model can be connected to the scope unit using a special tube. And, when using the traveling micrometer, the objective lens 10x allows measurement of up to 0.001 mm. The traveling micrometer is optional.
    (OCD10x, OBD2x, Stube, F tube included)
  3. The MRS series feature its revolver mechanism, which allows magnification to be changed quickly. Allowing frequent changing between several different magnifications, it is extremely useful for comparative observation. The revolver has three hole types, and allows selection between 2x and 10 x objective lenses.
  4. The ZLS series feature its zoom construction, enabling continuous enlarged observation. Standard spec. allows general magnification of 7x to 45x (field of vision 30 mm to 4.5 mm), and the optional 20 x lens allows continuous observation up to 14 x to 90 x (field of vision 15 mm to 2.3 mm). In each case, the operating distance is a fixed 93 mm. These single lens microscopes are compact and light, requiring very little space, and are widely used in the positioning and setting of machinery and device

Miruc Measure Scope Unit Features:

  • Powerful optical lenses combined with any portable digital camera up to 405x image magnification (depending on model of the CCD digital camera being used).
  • Dovetail stage Digital catch WiFi eyepiece for any microscope with far and stable image transmission to any output such as notebook, LCD screen and smartphones (through WIFI viewer app)Air pit powered by electric motor to pick up any item without fear of scratches or finger prints
    • Compatible to any model and brands of microscope
    • Unparalled variety of fittings to correspond to any kind of positioning coupled with smooth sliding action

SPESIFIKASI Miruc Monocular Measure Scope Unit

 Miruc Monocular Measure Scope Unit Ordering Guide:

When using eyepiece lens 10x

Eyepiece lens OC.WFD 10 x (standard)
Objective lens 1 x 2 x 3 x 4 x 5 x 6 x 8 x 10 x
Field of view mm φ 20 10 6.5 5 4 3.5 2.5 2
Working distance mm 176 85 63 48 39 33 27 20
General magnification 10 x 20 x 30 x 40 x 50 x 60 x 80 x 100 x
Minimum 1st reading mm 0.1 0.05 0.0333 0.025 0.02 0.0166 0.0125 0.01



When using the eyepiece lens 20 x

Eyepiece lens OC.WFD 20 x
Objective lens 1 x 2 x 3 x 4 x 5 x 6 x 8 x 10 x
Field of view mm φ 10.5 5.2 3.5 2.6 2.1 1.7 1.3 1.05
Working distance mm 176 85 63 48 39 33 27 20
General magnification 20 x 40 x 60 x 80 x 100 x 120 x 160 x 200 x
Minimum 1st reading mm 0.1 0.05 0.0333 0.025 0.02 0.0166 0.0125 0.01
