Untuk mendapatkan informasi lebih lengkap tentang:
Sisma EASY Laser Marking
Segera Hubungi Kami :
(62) 778 408 6403
(62) 815 3611 0114
sales@lfc.co.id
The Sisma "EASY" are intended for any small scale proffesional or even beginner in crafting their engraving product instantly. The Sisma "EASY" marking laser uses diode and fiber Ytterbium laser technology (YAG) and is especially suited for manually marking and engraving on metals.
The Sisma "EASY" laser marking model offer the benefits of a direct metal marking, non-contact, tear and abrasion resistant, permanent result for long term with the least cost possible.
The Sisma "EASY" is a innovatively pactical “all in one” laser marking system characterized by a great flexibility of use and equipped with a Z motorized axis at high precision and speed. Machine with a large sight glass and LED interior lighting. Available in 1st class closed version and 4th class open version with four range of power: 6W, 10W, 20W and 40W
SPESIFIKASI Sisma EASY Laser Marking
Sisma "EASY" marking laser 1st Class / 4th Class
| Average Output Power [W] | 6 | 10 | 20 | 40 |
| Wave Length [nm] | 1064 | 1064 | 1070 | 1070 |
| LASER TECHNOLOGY | Nd:YAG | Nd:YAG | Yb | Yb |
| Repetition Rate Range [KHz] | 20 | 1-100 | 2-200 | 1-1000 |
| Pulse Width [ns] | 30 | 35 | 200 | 10 - 240 |
| Max Pulse Energy [mJ] | 0,3 | 0,7 | 0,8 | 1,25 |
| M2 ≤ | 1,8 | 1,8 | 1,5 | 3 |
| Beam spot diameter f160 [μm] | 20 | 20 | 20 | 30 |
| Guide Laser | Class 2M Red Laser Diode; λ=650 nm; 2 mW | |||
| Temperature Range | Operative 10°C to 35°C | |||
| Cooling System | Forced-aired cooling | |||
| Z axis stroke [mm] | 290 | |||
| 4th axes | Optional | |||
| Power supply | 0,8 KW - 230V 50/60Hz 1ph | |||
| Weight and dimensions | 85 Kg - 560x760x850 h mm | |||
Harga Sisma EASY Laser Marking
Silahkan isi formulir di bawah ini untuk mendapatkan harga terbaik dari tim kami.
