Sylvac Depth Gauge S_Depth PRO
Segera Hubungi Kami :
(62) 778 408 6403
(62) 815 3611 0114
sales@lfc.co.id
Made with Swiss precision the 0-600mm Sylvac Depth Gauge S_Depth PRO is IP54 rated, has two reference points and has an automatic selection of measuring direction. Sylvac Depth Gauge S_Depth PRO is devised as a depth micrometer for measuring the depth of bores or various workpiece on maximum error of 30 µm. Due to its practical and swift interpolation on the vernier scale, this Swiss made depth gauge is assured to give you a repeatability of 10 µm. For improved accuracy, you can also use this versatile gauge with or without a fixture stand and can also be requested with 0.01 mm resolution.
Features :
- PRESET function
- Automatic switching of measuring direction
- Setting of the «constant» for measurement with cylindrical or spherical anvils (with accessory 805.6103)
- Additional bases available (see accessories)
- Measuring anvil with pin ø 4 mm (measuring ball probe M2.5 in standard)
Benefits :
- Inspection with jigs & fixture, automation inspection, and can also be combined for cutting alignment, measure vertical or horizontally relieved workpiece as in steel construction, tool-making and many more.
SPESIFIKASI Sylvac Depth Gauge S_Depth PRO
Sylvac Depth gauge S_Depth PRO Dimension Guide:
Sylvac Depth gauge S_Depth PRO Ordering Guide:
| 805.6605 | 805.6606 | ||
| Measuring range | mm | 300 | 600 |
| Max error | µm | 30 | 40 |
| Repeatability 1) | µm | 10 | 10 |
| A | mm | 335 | 545 |
| B | mm | 483 | 693 |
| S_Connect: Power | USB / RS232 / Digimatic / Wireless 2) | ||
| 2 references | • | ||
| PRESET function | • | ||
| Multiplication factor | • | ||
1) ± 1 digit
2) Sylvac cables. See accessories category
